15 - 2

Convenient Storage

Intelligent battery charging system makes this base a safe and convenient storage receptacle for your

Dolphin terminal.

Capacity

The base holds up to four Dolphin terminals. Each charging well charges each terminal independently of

the other wells.

Dimensions

Weight

Net Base weight: 694g [1.53 lbs.]

Note: Weight excludes packaging, cables and power supply.

427.11 mm

[16.80 inches]

98.8 mm

[3.89 inches]

59.75 mm

[2.35 inches]
